• Eight HART devices can be connected simultaneously with parallel scanning.
• Three-terminal electromagnetic isolation (1500 V) between host power and HART channels.
• RS485 and NET Ethernet interfaces with at least 1500 V isolation voltage.
• Modular design allowing online HART module replacement in any channel.
• Independent indicator lights for each channel to show communication and online status.
• Equipped with communication interfaces and operation/fault indicator lights.
• High-speed data refresh rate: ≥ 1 second per channel.
• Supports Ethernet interfaces with a minimum speed of 100 Mbps.
• Ability to read all HART IDs using proprietary HART commands.
• Supports Telnet remote settings, configuration, and operating modes.
• Firmware program updates are fully supported.
• Standard DIN rail mounting compatible; no effect on 4–20 mA analog signal accuracy.
• Loop resistance support up to 250 ohms.
• Compatible with HART protocol Ver5.0 and higher.
• Maintains signal integrity under power failure or fault conditions.

All products come with a three-year warranty. If you encounter any problems during use, technical support is available to assist with configuration and troubleshooting.
